Artificial Grass Installation Tips

You will find out how you can make your yard an eco-friendly zone and save money at the same time. We have everything you need to complete your project, from turf staples, infill to other installation accessories. We are here to help, and please watch our installation video below.

Green Ridge Artificial Grass Installation in Rancho Cucamonga, CA

Medium-sized River Rock, DG & Various Succulents w/drip line throughout the Hillside.

Clear the work area of all unwanted tree roots, mulch, large rocks, and any remaining construction debris obstructions. Utilize sod cutters, shovels, and pick axes to remove grass and vegetation.

Step 1: Pre-Installation

Remove existing materials. Demolition involves removing existing materials, whether soil, weeds, or any substance above ground. By rough grading the area and uncovering everything underneath, including electric wiring, irrigation, pipes, etc.–we can get a solid sub-base for the project.

• Utilize a sod cutter, shovel, and pick axes to remove grass, sod, and vegetation.
• Remove all unwanted tree roots, mulch, and large rocks.
• Clear the ground of any remaining construction debris or obstructions

Cap sprinklers.

In this phase, we also cap any existing sprinklers that will not use. It is essential to cap sprinklers at the pipe level instead of the rising. This avoids any leakage that may occur between the two. Modify sprinkler irrigation or drainage.

Relocate sprinklers, modify existing irrigation lines, and add any required drainage. Be sure to backfill and mark the location of any new sprinklers to avoid depressions or low spots.

When locating any wiring, electrical sprinklers, etc., move it inward and away from any hardscape or perimeter by six to eight inches. This should prevent accidental damage when it comes time to secure the turf edge with nails. Once moved, lay all wiring on top of the subgrade, surfacing with U-nails.

Install Bender Board

Installing the bender board is essential as it provides a clean line and separation for the plants, bed, and turf areas.

Step 2: Base Preparation

As we begin the sub-base process, laying down the weed barrier cloth first is recommended. Installing the base material is crucial to maintain the stability and integrity of the turf.

Gravel DG Mix

• The next step is to install the base material. This is a unique mixture of gravel and sand, which allows for proper drainage. Install 3 inches in depth. For a non-pet landscape installation, should install the base material to a depth of 3 inches.

Properly distribute and level base. Proper base distribution and leveling are important for sloping away from living areas and the installed drainage area. The appropriate base installation ensures the turf will have a smooth level appearance upon completing the project.

Step 3: Compacting Base

Next, we wet the existing base to allow for proper settling.

Compaction

• The Compaction is accomplished by vibrating, tamping, and rolling the gravel. This establishes a solid base to drive the nails while installing the turf. Can do any additional leveling or grading at this time.

Make sure to measure the project area and carefully design the layout to minimize the number of seams in the turf. The best method is to lay the grass out and trace from the top where you’ll be making your cuts.

There are 2 different tools you’ll need for this process.

• Long Pile Carpet Cutter.Carpet knife.
• All cuts must be made fro

the back side of synthetic turf to see the stitch rows. System.

Step 4: Custom Fitting Turf

When trimming the turf to fit the area properly, you should over-cut the turf by one inch along the edges. This provides the excess turf necessary for tucking. When in doubt, cut the turf fatter as you can always trim it later. When seaming, it is recommended to use the seaming tool. Once cut using the seaming tool, line it up accordingly.

Cutting the Turf

Use the “S: Seam Tool: Cutting the turf in an s-shape avoids the possibility of the turf pieces pushing against each other’s angles, which in many cases would create the illusion of discoloration in the area of the seam. Install nails every six inches along the edge. Install nails along the edge by placing them six inches apart, driving them down ¾ of the way.

Staples or Nails

Nails or Staples used in the field should be applied as necessary to prevent the movement of turf. As before, drive the nails down ¾ of the way. When finishing the nails, separate the grass to avoid pulling down the blades with the nail. The nail is then hidden with the grass blade at the base of the mat.

Don’t drive the nails too deeply in the ground as it will cause the turf to be pulled down, creating dimples on the surface—secure seams with U-nails every six inches. During the seaming process, six-inch u-nails are used to join the turf together.

The two seams are butted up against each other with u-nails spaced six inches apart. The finishing process with the u-nails is the same as before. Separate the grass to avoid the blades being pulled down with the u-nail. The u-nail is then driven to the same level of the mat and then hidden with the grass blades.

Step 5: Tucking Turf Edges

Tucking the turf involves hiding the edges of the turf against any hardscape or edging border by using a metal bar called a wonder bar. The side edges of the turf give it a good clean plush look.

Step 6: Applying Filler

In this phase, a powder brush is used. The heavy bristled brush is used to pull against the grain of the grass, causing it to stand up in preparation for applying the Infill sand. Next, apply the infill sand.

The Zeo Clean sand is anti-bacterial and not harmful to pets or children. Spread the granules evenly throughout the turf installation. This acts as a balance to hold the blades upright and gives the turf more weight.

Step 7: Final Groom

The final grooming step involves power brushing the turf once again, lightly, to force the Zeo Clean Infill granules into the base of the turf for settling and optimal stability. Follow up the process to remove any excess debris.
